Design and Features, etc

General Characteristics

How to Select a Solenoid

Ordering Infomation



Product

Wattage Continuous
/ Intermittent

Force in Newtons at the Stated Wattage Stroke (mm)

0.5

1

1.5

2

2.5

3

Size133
(64)

3



0.325



0.175





12



1.5



0.74



0.34

Product

Wattage Continuous
/ Intermittent

Force in Newtons at the Stated Wattage Stroke (mm)

2mm

4mm

6mm

8mm

10mm

12mm

14mm

16mm

Size130
(65)

4

0.6

0.27

0.15

0.04









16

2.3

1.2

0.65

0.425

0.27







Size170
(66)

4.5

1.3

0.54

0.35

0.23

0.16







18

3.7

2.25

1.5

0.95

0.65

0.4





Size190
(67)

7

3

1.7

1

0.73

0.58

0.47





28

9

5.25

3.6

2.8

2.25

1.85





Size253
(68)

8

4.6

2.4

1.3

0.68

0.325







32

17

8.9

4.9

2.8

1.6

0.75





Size250
(69)

10

10

5.25

3.5

2.5

1.8

1.5

1.25



40

24

17

13

9

7

5.75

4.85



Size320
(70)

13

22.5

14

8.5

6

4.5

3.5

2.75

1.85

52

40

32

25

19

16.5

14

11

9.9

Product

Wattage Continuous
/ Intermittent

Force In Newton Meters at Stated Wattage Stroke (mm)

5mm

10mm

15mm

20mm

25mm

30mm

Size380
(71)

17

20

9.5

5.5

3.8

2.9

2

68

47.5

30

22

17

13

9
